KOOL-AIR R1234yf HYDROCARBONS & RECHARGE KITS
• Leak Stop • Enhancer • Oil charge
R1234yf Premium Leak Stop & Recharge Kit
Part # 7204
Each kit contains:
• 2 x Premium Repla 134/1234 (AR4247)
• 1 x Extreme Ultra - Leak Stop (TR1163.AL01)
• 1 x R1234yf Installation Adapter (RK1423.S1)
• 1 x Installation Hose w/ Gauge (AR4252YF)
R1234yf Premium Oil Charge
Part # 7206
Each kit contains:
• 1 x 2oz Syringe Premium PAG Oil (OL6058.E01)
• 1 x R1234yf Installation Adapter (RK1423.S1)
Premium Repla134/1234yf
Specifically designed for automotive AC systems
Equivalent to: 17oz (481g) R134a - 12oz (340g) R1234yf
Part # AR4247
Features & Benefits:
• Reduces vent temperatures & cools vehicles faster
• Environmentally Friendly
• High Performance
• Non-Toxic
• Non O-Zone Depleting
• Safe for R1234yf and R134a Systems
• No ODS license required to purchase or install
• Easy to install
Available In:
• AR4247 - 6oz Can
• AR4247-20 - Case of 20
• AR4247HP - Case of 6
FMSI's Repla 134/1234yf is a safe, natural and
purified hydrocarbon refrigerant and is suitable
for both R134a & R1234yf Systems.
By using less volume and operating at lower
pressures, its high performance formula,
contributes to extending the service life
of AC systems.
A Safe alternative to HFC, HFO, HCS & HCFC,
(OE Refrigerants) Non-toxic and
enviromentally friendly.
NOT AVAILABLE IN USA Revolutionize Leak Testing for R1234yf Systems
Part # 7211
Complete Package Includes:
• 2 Cans of Hydrocarbon Refrigerant
• 1 Syringe of UV Dye
• Connection Adapter & Hose
THE PROBLEM
R1234yf refrigerant is expensive,
costing $80-$100 per pound,
and leaks during testing can result
in significant financial loss with no recovery options.
OUR SOLUTION
The Hydrocarbon Refrigerant Testing Package offers a cost-effective and eco-friendly
alternative for testing R1234yf systems:
• Affordable Testing: Replace R1234yf with a pure, high-quality hydrocarbon refrigerant.
• Complete Package includes:
• 2 Cans of Hydrocarbon Refrigerant
• 1 Syringe of UV Dye
• Connection Adapter & Hose
• Single-Use Convenience: Designed for precise and effective testing.
HOW IT WORKS
1. Connect the adapter to the low side of the vehicle’s HVAC system.
2. Perform a full charge with the hydrocarbon refrigerant.
3. Install the UV dye.
4. Identify leaks easily with UV light detection. (This may take a few days)
KEY BENEFITS
• Cost Savings: Reduce testing expenses dramatically.
• Safe & Compatible: Designed for use in R1234yf systems, including vehicles
with combustion engines, hybrids, and EVs.
• Eco-Friendly: Hydrocarbon refrigerant is non-ozone-depleting and requires no ODP license.
NOT AVAILABLE IN USA
24” Extended Installation Hose
Part # AR4252YF
R1234yf Systems
AR4245: Can Tap INSTALLATION KIT
TO INSTALL REPLA 1234YF SMALL CANS WITH GAUGE SET
Part # AR4257 (Consists of AR4245, MT0432, MT1799)
MT0432: 1/2” Acme Female
to 1/4” Sae 7/16”- 20 Male
MT1799: 1/4” 7/16” - 20 Sae Female
to 1/2” Acme Male left hand tread
MT0405: Yellow Hose
1234YF Hose
Replacement Gasket for Tap End
Part # AR4252YFG
Low side 24” extended installation hose
with gauge suitable for installing
hydrocarbons, sealants and oil charges
(The Hose & Refrigerant
not included)
