AIR CONDITIONING HOSE & FITTINGS
• SAE J2064 Hose • Crimping Tool • Ferrules
#6 ID: 5/16” OD: 3/4”
Standard Barrier Hose
#8 ID:13/32” OD: 29/32”
Standard Barrier Hose
Part # Size Length
Part # Size Length
FMSI Automotive Hardware’s SAE J2064 - R134a & R1234yf Barrier A/C hose
is designed for automotive refrigerant systems with protection against
refrigerant contamination and reduced permeation
Features:
• Compatible with R12, R134a, R1234yf & Hydrocarbon Refrigerants
• 2900 PSI Burst Pressure
• 500 PSI Working Pressure
• Constructed with Low Permeation Elastomer Liner
• Meets SAE J2064
• Durable Outer Cover Resistant to Abrasion, Oil, Grease, Ozone & Coolants
• Handles Temperature Extremes of -40ºF (-40ºC) to 275ºF (135ºC)
• Available in 5/16”, 13/32”, 1/2”, 5/8” & 3/4” I.D. and in Lengths of 5’, 12’ & 25’ Coils
#10 ID: 1/2” OD: 1”
#12 ID: 5/8” OD: 1.10”
#14 ID: 3/4” OD:
Standard Barrier Hose
Standard Barrier Hose
Standard Barrier Hose
Part # Size Length
Part # Size Length
Part # Size Length
AR516-5 #6 - 5/16” I.D. 5 ft
AR1332-5 #8 - 13/32” I.D. 5 ft
AR12-5 #10 - 1/2” I.D. 5 ft
AR58-5 #12 - 5/8” I.D. 5 ft
TBA #14 - 3/4” I.D. 5 ft
AR516-12 #6 - 5/16” I.D. 12 ft
AR1332-12 #8 - 13/32” I.D. 12 ft
AR12-12 #10 - 1/2” I.D. 12 ft
AR58-12 #12 - 5/8” I.D. 12 ft
TBA #14 - 3/4” I.D. 12 ft
AR516-25 #6 - 5/16” I.D. 25 ft
AR1332-25 #8 - 13/32” I.D. 25 ft
AR12-25 #10 - 1/2” I.D. 25 ft
AR58-25 #12 - 5/8” I.D. 25 ft
TBA #14 - 3/4” I.D. 25 ft
#6 ID: 5/16” OD: 9/16” #8 ID:13/32” OD: 43/64” #10 ID: 1/2” OD: 3/4” #12 ID: 5/8” OD: 59/64” #14 ID: 3/4” OD: 1-1/8”
Reduced Barrier Hose
Reduced Barrier Hose
Reduced Barrier Hose
Reduced Barrier Hose
Reduced Barrier Hose
Part # Size Length
Part # Size Length
Part # Size Length
Part # Size Length
Part # Size Length
RB516-5 #6 - 5/16” I.D. 5 ft
RB1332-5 #8 - 13/32” I.D. 5 ft
RB12-5 #10 - 1/2” I.D. 5 ft
RB58-5 #12 - 5/8” I.D. 5 ft
RB34-5 #14 - 3/4” I.D. 5 ft
RB516-12 #6 - 5/16” I.D. 12 ft
RB1332-12 #8 - 13/32” I.D. 12 ft
RB12-12 #10 - 1/2” I.D. 12 ft
RB58-12 #12 - 5/8” I.D. 12 ft
RB34-12 #14 - 3/4” I.D. 12 ft
RB516-25 #6 - 5/16” I.D. 25 ft
RB1332-25 #8 - 13/32” I.D. 25 ft
RB12-25 #10 - 1/2” I.D. 25 ft
RB58-25 #12 - 5/8” I.D. 25 ft
RB34-25 #14 - 3/4” I.D. 25 ft
Reduced Barrier Crimp Fitting
Standard Hose Ferrules
Reduced Hose Ferrules
Part # Description
Part # Tube Size
Part # Tube Size
5800 #6 Reduced Barrier Hose Crimp
AC0221 # 6 to 5/16”
AC0217 # 6 to 5/16”
5801 #8 Reduced Barrier Hose Crimp
AC0222 # 8 to 13/32”
AC0218 # 8 to 13/32”
5802 #10 Reduced Barrier Hose Crimp
AC0223 # 10 to 1/2”
AC0219 # 10 to 1/2”
5803 #12 Reduced Barrier Hose Crimp
AC0224 # 12 to 5/8”
AC0220 # 12 to 5/8”
Hydraulic Crimping Tool
Asst # 71500M
Asst # 0148
Ferrule Assortment
(16Pcs)
Included with purchase
of 71500M
Key Benefits:
• Ideal for shop and field applications
• Lightweight & handheld
• Makes crimping barbed and beaded fittings easy
• Dies covering #6, #8, #10, & #12 in Standard & Reduced barrier hose
• Dies snap into tool quickly requiring no pins or screws
• Secure molded case
