AIR CONDITIONING REPAIR FITTINGS
• Premium Aluminum Tube Joining
Mechanical Tube Joiner German Technology... Used World Wide
• For universal use, independent of vehicle type and model year
• No waiting for expensive OE parts
• No welding, soldering or threading necessary
• In most cases, the faulty line may not even need to be removed
• OEM trusted for over 30 years
Mechanical Tube Joiner Jaw Sets LOKPREP - Anaerobic Sealant
THE SET INCLUDES 2 PCS
*JAWS REQUIRED (NOT INCLUDED)
Part # Description
5131 Ratcheting aluminum tubing joiner
5131M Double pivot tool
• Specially developed for aluminum tube joining
• *Must be used in All LOK-RING assemblies
• Compensates for flaws and unevenness in tubing
• Ensures that fittings are hermetically sealed
• Anaerobic sealant Will Not dry out or become brittle
• Set Up Time 10 mins After Closing
Part # 5140
IMPORTANT
Ensure Lokprep is evenly distributed 360º
around tubing to ensure leak free connection.
65g
* USED W/ 5131 &
5131M TOOL
Part # Tube Size
5142HP 5/16” (8mm) Tubing Joiner Jaw
5132HP 3/8” (10mm) Tubing Joiner Jaw
5133HP 1/2” (12mm) Tubing Joiner Jaw
5134HP 5/8” (14mm -16mm) Tubing Joiner Jaw
5135HP 3/4” (19mm) Tubing Joiner Jaw
Aluminum Block Off Caps
Aluminum Tube Unions
Aluminum to Hose Unions
*INCLUDED
Reduced Barrier A/C Hose
Part # Tube Size
Part # Tube Size
Part # Hose Size Tube Size
5265 5/16” (8mm) Aluminum Block Off
5143 5/16” (8mm) Aluminum Union
5381 # 6 (5/16”) 3/8”
5266 3/8” (9.5mm) Aluminum Block Off
5136 3/8” Aluminum Union
5384 # 12 (5/8”) 3/4”
5267 1/2” (12mm) Aluminum Block Off
5137 1/2” Aluminum Union
90º Tube to Tube Aluminum Elbow Unions
5268 5/8” (16mm) Aluminum Block Off
5138 5/8” (16mm) Aluminum Union
5350 3/4” (19mm) Aluminum Block Off
5139 3/4” (19mm) Aluminum Union
5351 14.5mm Aluminum Block Off
5150 7/8” (22mm) Aluminum Union
5259 10mm Aluminum Union
Hose to Tube Aluminum Fittings
5260 12mm Aluminum Union
Part # Tube Size
STANDARD
& METRIC
Standard Barrier A/C Hose Reduced
5261 14mm Aluminum Union
5395 3/8” 90º Aluminum Elbow
5262 15mm Aluminum Union
5396 1/2” 90º Aluminum Elbow
5263 18mm Aluminum Union
5397 5/8” (16mm) 90º Aluminum Elbow
Reducer Aluminum Unions
Hose Lok to Tube Aluminum Fittings
Part # Tube Size Part #
STANDARD
5471 5/16” Tube to # 6 Hose 5470
5248 3/8” Tube to # 6 Hose 5275
5356 12mm Tube to # 8 Hose 5357
5249 1/2” Tube to # 8 Hose 5276
Part # Tube Size
5476 14mm Tube to # 10 Hose —
5246 5/8” to 1/2” Reducer Union
5475 15mm Tube to # 10 Hose —
5247 3/4” to 5/8” Reducer Union
5250 5/8” Tube to # 10 Hose 5277
5374 3/8” to 5/16” Reducer Union
— 5/8” Tube to # 12 Hose 5472
5399* 14.5mm to 16mm Reducer Union
5251 3/4” Tube to # 12 Hose 5278
* Honda Odyssey & Pilot
Standard Barrier A/C Hose Reduced
Part # Tube Size
5252 3/8” Tube to # 6 Hose 5352
5253 1/2” Tube to # 8 Hose 5353
5254 5/8” Tube to # 10 Hose 5354
5255 3/4” Tube to # 12 Hose 5355
