AIR CONDITIONING REPAIR FITTINGS
• Aluminum Hose to Tube Joining
45º Tube to Hose Repair Fitting
1 1
Much More Sealing
Area than O-Ring
2
3
Part # Description
5627 5/16” Tube x 45º to # 6 Hose (RB516 hose)
5628 3/8” Tube x 45º to # 6 Hose (RB516 hose)
5629 1/2” Tube x 45º to # 8 Hose (RB1332 hose)
Assemble
5630 5/8” Tube x 45º to # 10 Hose (RB12 hose)
5631 3/4” Tube x 45º to # 12 Hose (RB58 hose)
90º Tube to Hose Repair Fitting
Part # Description
5623 5/16” Tube x 90º to # 6 Hose (RB516 hose)
5624 3/8” Tube x 90º to # 6 Hose (RB516 hose)
5625 1/2” Tube x 90º to # 8 Hose (RB1332 hose)
5626 5/8” Tube x 90º to # 10 Hose (RB12 hose)
Push Together
Tighten
Self-Adjusting
Anti-vibration Tension Ring
Anodized Nut to Prevent
Premature Corrosion
(NO SPECIALTY TOOLS REQUIRED)
Easily Repair Leaking Air Conditioning, Coolant, Transmission &
Oil Cooler Lines with FMSI Automotive Hardware’s Range of Line Splices,
Block Off Caps & Line Set Assortments.
Asst # 0132M Asst # 0117M
5632 3/4” Tube x 90º to # 12 Hose (RB58 hose)
45º & 90º Line Splices (Standard)
Part # Description
76061 1/2” - 45º Line Splice
76062 3/8” - 45º Line Splice
76063 5/16” (8mm) - 45º Line Splice
76064 5/8” (16mm) - 45º Line Splice
76090 76071 76072 76073 76074 76091 14.5mm to 5/8”(16mm) - 45º Line Splice
1/2” - 90º Line Splice
3/8” - 90º Line Splice
5/16” (8mm) - 90º Line Splice
5/8” (16mm) - 90º Line Splice
14.5mm to 5/8”(16mm) - 90º Line Splice
5/16”x12’
x2
13/32”x12’
x1
1/2”x12’
x2
5/8”x12’
x1
6 Rear A/C Line Set Assortment Includes
(12) Fittings (6) 12ft Reduced Barrier A/C Hoses
Honda Odyssey / Pilot Repair
Asst # 0133 19 pc A/C Line Splice &
Block Off Cap Assortment
5/16” to 3/4” - Aluminum Tubing Included
Asst # 0157
High & Low Side Service Port Fittings
Part # Description
76201 Line Splice Low Side Service “T” for 1/2” OD line
76202 Line Splice Low Side Service “T” for 3/8” OD line
76204 Line Splice Low Side Service “T” for 5/8” OD line
76212 Line Splice High Side Service “T” for 5/16” OD line
76213 76214 Line Splice High Side Service “T” for 3/8” OD line
Line Splice High Side Service “T” for 1/2” OD line
7 pc Rear A/C Line Block Off Cap Assortment
5/16” to 3/4”
Asst # 0165M 8 pc Metric Rear A/C Block Off Cap Assortment
8mm to 16mm (Includes Honda Odyssey/Pilot)
Asst # 0166
High Side Inline Filters (Standard & Metric)
Part # 76100
Part # 77100
(Standard)
(Metric)
High Side Filter
High Side Filter
5/16”, 3/8” & 1/2”
10mm & 12mm
OE-Approved
Protect the condenser and other
new A/C components
• Traps metal shavings and non-metallic debris
• Tapered design forces debris to side
• Allows continual refrigerant flow, even with filtration
• Works with TXV or CCOT systems
12 pc Metric A/C Line Splice & Block Off Cap
Assortment 8mm to 16mm (Includes Odyssey/Pilot)
19 pc A/C Line Splice & Block Off Cap
Assortment - 5/16” to 3/4”
